Metro DataVac C5 3 Series User Manual

13
SERVICE and REPLACEMENT PARTS
C5 1 & 3 SERIES CABINETS
Item # Replacement Part No. Description
CABINET BODY
1 RPC5-19-FCDR COMPLETE FULL HEIGHT CLEAR DOOR
RPC5-17-FCDR COMPLETE
3
/4 HEIGHT CLEAR DOOR
RPC5-15-FCDR COMPLETE
1
/2 HEIGHT CLEAR DOOR
RPC5-39-TCDR COMPLETE TOP CLEAR DUTCH DOOR
RPC5-39-BCDR COMPLETE BOT. CLEAR DUTCH DOOR
2 RPC5-39-FSDR COMPLETE FULL HEIGHT SOLID DOOR
RPC5-37-FSDR COMPLETE
3
/4 HEIGHT SOLID DOOR
RPC5-35-FSDR COMPLETE
1
/2 HEIGHT SOLID DOOR
RPC5-39-TSDR COMPLETE TOP SOLID DUTCH DOOR
RPC5-39-BSDR COMPLETE BOT. SOLID DUTCH DOOR
3 RPC14-119 DOOR HINGE ( QTY. 1)
4 RPC14-118 DOOR LATCH, OFFSET HANDLE
RPC14-118A DOOR LATCH, FLUSH HANDLE
5 RPC06-910A FULL HEIGHT CLEAR DOOR GASKET
RPC06-910B
3
/4 HEIGHT CLEAR DOOR GASKET
RPC06-910C
1
/2 HEIGHT CLEAR DOOR GASKET
RPC06-910D CLEAR DUTCH DOOR GASKET
6 RPC06-916A FULL HEIGHT SOLID DOOR GASKET
RPC06-916B
3
/4 HEIGHT SOLID DOOR GASKET
RPC06-916C
1
/2 HEIGHT SOLID DOOR GASKET
RPC06-916D SOLID DUTCH DOOR GASKET
7 B5DNB 5" BRAKE CASTER
RPQC02-248 6" BRAKE CASTER
8 B5DN 5" SWIVEL CASTER
B5DNR 5" RIGID CASTER
RPQC02-247 6" SWIVEL CASTER
9 RPC5-SSLEG-1 STATIONARY EQUIPMENT LEG (QTY. 1)
10 RPC5-DPTRH POLY DRIP THROUGH & SCREWS
11 RPC06-179 DRIP PAN
12 RPC5-RHANDLE REAR HANDLE & SCREWS
(USED ONLY ON 1 SERIES)
13 RPC5-TRVL TRAVEL LATCH
14 RPC5-1-BMPR 1 SERIES CORNER BUMPERS
(2 FRONT, 2 REAR & SCREWS )
15 RPC13-106 POWER CORD BUSHING
16* C5-13-FW-9 FULL HEIGHT FIXED WIRE SLIDES
C5-13-FW-7
3
/4 HEIGHT FIXED WIRE SLIDES
C5-13-FW-5
1
/2 HEIGHT FIXED WIRE SLIDES
17* C5-13-U-9 FULL HEIGHT UNIV SLIDES & UPRIGHTS
C5-13-U-7
3
/4 HEIGHT UNIV SLIDES & UPRIGHTS
C5-13-U-5
1
/2 HEIGHT UNIV SLIDES & UPRIGHTS
18* C5-13-L-9 FULL HEIGHT LIP LOAD SLIDES
C5-13-L-7
3
/4 HEIGHT LIP LOAD SLIDES
C5-13-L5
1
/2 HEIGHT LIP LOAD SLIDES
19 C5-USLIDECPR CHROME UNIV WIRE SLIDES — 1 PAIR
C5-USLIDESPR SS UNIVERSAL WIRE SLIDES —1 PAIR
20 C5-SHELF ACCESSORY SHELF
(USED WITH UNIVERSAL UPRIGHTS)
Item # Replacement Part No. Description
OUTSIDE POLY PANELS ON C5 3 SERIES CABINETS
23 RPC3-TPNL-BG BEIGE TOP PANEL — INCLUDES SCREWS
RPC3-TPNL-BU BLUE TOP PANEL — INCLUDES SCREWS
RPC3-TPNL-GY GRAY TOP PANEL — INCLUDES SCREWS
RPC3-TPNL-RE RED TOP PANEL — INCLUDES SCREWS
24 RPC3-SD27-BG BEIGE 27" SIDE PANEL —
INCLUDES SCREWS
RPC3-SD27-BU BLUE 27" SIDE PANEL —
INCLUDES SCREWS
RPC3-SD27-GY GRAY 27" SIDE PANEL —
INCLUDES SCREWS
RPC3-SD27-RE RED 27" SIDE PANEL —
INCLUDES SCREWS
25 RPC3-SD21-BG BEIGE 21" SIDE PANEL —
INCLUDES SCREWS
RPC3-SD21-BU BLUE 21" SIDE PANEL —
INCLUDES SCREWS
RPC3-SD21-GY GRAY 21" SIDE PANEL —
INCLUDES SCREWS
RPC3-SD21-RE RED 21" SIDE PANEL —
INCLUDES SCREWS
26 RPC3-IA-BTPNL BOTTOM SIDE PANEL —
INCLUDES SCREWS
27 RPC3-IA-RTNR MIDDLE PANEL RETAINER —
INCLUDES SCREWS
28 RPC5-3-BASECLP BOTTOM PANEL CLAMP & SCREWS
29 RPC53-5URT* FULL &
1
/2 HEIGHT UNIV UPRIGHTS
(QTY. 1)
*(Full height cabinet uses same uprights)
RPC53-7URT
3
/4 HEIGHT UNIV UPRIGHTS (QTY. 1)
30 RPC519-PKG FULL &
3
/4 HEIGHT 1 AND 3 SERIES
CABINET RETURN PACKAGING
RPC515-PKG
1
/2 HEIGHT 1 AND 3 SERIES
CABINET RETURN PACKAGING
120 volt
*See pages 4 and 5 for slide identification. All slides
sold in pairs. Universal slides include uprights.
