Metrohm Optrode - 2 Overview; Figure 1 Optrode - Overview

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
4
￭￭￭￭￭￭￭￭
Optrode
2 Overview
1 4
5
6
7
8
9
2
3
Figure 1 Optrode – Overview
1
USB plug
For supplying the sensor with power.
2
SGJ sleeve
3
Storage vessel (6.2008.040)
4
Sensor F plug
For connecting to a titrator (connector Ind.).
5
Magnetic switch
For switching between the LEDs.
6
Optical circuit board
With wavelength display.
7
Glass shaft
8
Measuring gap
Light path = 10 mm.
9
Photodiode
For measuring the intensity of light.
