3 Installation
Optrode
￭￭￭￭￭￭￭￭
7
In order to connect the Optrode's USB cable to a Titrino plus, a USB Mini
(OTG) - USB A (6.2151.100) adapter is required (see figure).
Figure 7 Connecting the Optrode to a Titrino plus
3.4 Power supply with USB power supply unit
A 6.2166.000 USB power supply unit is available if power to the Optrode
cannot be supplied via a titrator's USB port. This USB power supply unit
can be connected to a socket directly. The cable for supplying the
Optrode with power can be connected to the USB port on the USB power
supply unit.
3.5 Installing the Optrode
NOTE
Ensure that the sensor is not exposed to direct sunlight and avoid dis-
ruptive light reflections.
Install the Optrode as shown in the figure below.
