Metrohm Optrode - Figure 8 Diagrams Showing Propeller Stirrer, Sensor and Titration Tip During a

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
3 Installation
Optrode
￭￭￭￭￭￭￭￭
9
1
2
3
1
2
3
a)
b)
Figure 8 Diagrams showing propeller stirrer, sensor and titration tip
during a titration. a) clockwise stirring direction, b) counter-
clockwise stirring direction.
1
Propeller stirrer
2
Sensor
3
Titration tip
