Metronix ARS 2100 SE User Manual

Page 53
The ARS 2100 SE series servo drive also features a sine modulation or alternatively a sine modulation
with third harmonic. This increases the effective converter output voltage. The type of modulation can
be selected via the Metronix ServoCommander
®
. The default setting is sine modulation.
If the sine modulation with third harmonic is used, the controllable upper motor speed
limit increases due to the higher control reserve of the PWM output stage.
Table 30: Output voltage at the motor terminals in the case of a DC bus circuit voltage
(U
ZK
) of 360 V
Output voltage converter Output voltage at the motor terminals
U
out,(sin)
U
LL,motor
= approximately 210 V
eff
U
out,(sin+sin3x)
U
LL,motor
= approximately 235 V
eff
Product Manual „Servo drives ARS 2100 SE“ Version 5.0

Metronix ARS 2100 SE Specifications

General

Output Frequency	0 - 599 Hz
Control Mode	Position, Velocity, Torque
Communication	CANopen
Protection Features	Overvoltage, Overcurrent, Overtemperature
Communication Interface	CANopen
