Technical data Page 13
Range ARS 2302 FS ARS 2305 FS ARS 2310 FS
DOUT0 Operational state 24 V, max. 100 mA
DOUT1 Freely configurable 24 V, max. 100 mA
DOUT2 Freely configurable, optional use
as input DIN10
24 V, max. 100 mA
DOUT3 Freely configurable, optional use
as input DIN11
24 V, max. 100 mA
DOUT4 [X6] Holding brake 24 V, max. 2 A
Analog inputs and outputs [X1]:
High-resolution analog input:
AIN0
±10V input range, 16 Bit, differentially,
< 250µs delay time
Analog input:
AIN1
Optionally, this input can also be
parameterized as digital input
DIN AIN1 with a switching
threshold at 8V.
±10V, 10 Bit, single ended,
< 250µs delay time
Analog input:
AIN2
Optionally, this input can also be
parameterized as digital input
DIN AIN2 with a switching
threshold at 8V.
±10V, 10 Bit, single ended,
< 250µs delay time
Analog outputs:
AOUT0 and AOUT1
±10V output range, 9 bit resolution, f
Limit
> 1kHz
Incremental encoder input [X10]:
Parameterisable number of encoder
lines
1 – 2
28
lines/rev
Trace signals As per RS422 specification
Max. input frequency 1000 kHz
Pulse-direction interface As per RS422 specification
Output supply 5 V, max. 100 mA
Incremental encoder output [X11]:
Number of lines Programmable 1 – 2
13
and 2
14
lines/revolution
Connection level Differential / RS422 specification
Encoder signals A, B, N As per RS422 specification
speciality N-Trace disconnectible
Output impedance R
a,diff
= 66 Ω
Limit frequency f
Limit
> 1,8 MHz (lines/s)
Edge triggering
(minimum pulse width)
Can be limited by parameters
Output supply 5 V, max. 100 mA
Ethernet [X18]:
RJ45, 10/100 MBaud (auto select)
USB [X19]:
According to USB 2.0, USB-B, slave-client
SD card slot
SD, SDHC and MMC - FAT12, FAT16 and FAT32
