Metronix ARS 2302 User Manual

Electrical installation Page 26
The signals for the temperature sensor "MT-" (PIN 4) and "MT+" (PIN 5) on the motor
connector plug [X6] are not situated on safety extra-low voltage
(PELV - protective extra-low voltage). The connections are designed for non-PELV
temperature sensors. The isolation to PELV is part inside the ARS 2000 FS.
If the power supply is too high, the angle encoder can be destroyed! Make sure that you
have set the correct supply voltage before connected to [X2B]!
