Meyer's VB280 - Model Specifications

2 | P a g e M o d e l V B 2 8 0
MODEL SPECIFICATIONS
Width of Box Inside
61”
Overall Width
118”
Length of Box Inside
214”
Depth
36”
Overall Length
29’3”
Overall Height - Front
106”
Ground Clearance
16-1/2”
Capacity (Struck)*
280 ft3
Capacity (Heaped)*
470 ft3
Empty Weight (lbs.)
10,500
Loading Height
72”
Apron Chain (Standard)
Twin #67P11
Beaters
Twin Ø30” Vertical Beaters
w/ 10MM Thick Spiral Flighting
Spindles / Hubs (Tandem Axle)
(4x) Ø3” Spindles / (4x) 7,500 lb. Hubs
Spindles / Hubs (Single Axle)
(2x) Ø3-3/8” Spindles / (2x) 15,000 lb. Hubs
Standard Tire Size (Tandem Axle)
425-65R22.5
Standard Tire Size (Single Axle)
1600R20
PTO Speed
1000 RPM Standard
540 RPM Optional
Min. Recommended
Tractor Horsepower
135 HP
Min. Recommended
Hydraulic Flow
15 GPM
*Capacities calculated per ASAE 324.2 JUL2018
(Volumetric Capacity of Open-Top Manure Spreaders – Dual Rating Method)
