60 | P a g e M o d e l V B 2 8 0
HYDRAULIC SYSTEM PARTS, APRON DRIVE, ELECTRIC FLOW CONTROL
OPEN CENTER SYSTEMS WITH A FIXED DISPLACEMENT PUMP, BALL VALVE SHOULD BE OPEN.
CLOSED CENTER SYSTEMS WITH A VARIABLE DISPLACEMENT PUMP, BALL VALVE MAY BE CLOSED.
SEE PAGE 15 FOR DETAILS.
