HYDRAULIC SYSTEM PARTS, APRON DRIVE, MANUAL FLOW CONTROL
KEY
PART NO.
QTY.
DESCRIPTION
1
E00486-00
1
VALVE, MANUAL FLOW CONTROL, RD-1910-16
2
6400-8-10
1
ADAPTER, 10MORB-08MJIC
3
6801-8-10
1
ADAPTER, 90° ELBOW, 10MORB-08MJIC
4
2700-LN-8-8
3
BULKHEAD, STRAIGHT, 08MJIC-08MJIC
5
6403-NWO-10-08
1
ADAPTER, 10MORB-08MORB
6
E00497-00
1
BALL VALVE, #8 SAE, 72-903
7
6400-8-8
1
ADAPTER, 08MORB-08MJIC
8
6600-8-8-8
1
ADAPTER BRANCH TEE, 08MJIC-08MJIC-08FJS
9
2764-LN-8-8
1
BULKHEAD ADAPTER, 08MORB-08MJIC
10
E00496-09
1
CHECK VALVE, LT-8-0
11
2705-8-8
1
BULKHEAD ADAPTER, 08FP-08MJIC
12
66436
1
PIPE NIPPLE, ½” x 4” SCH40
13
E00496
1
CONNECTOR SLEEVE, CONTROL HOSE
14
E21443
1
SPEED CONTROL POINTER
15
6801-8-10
2
ADAPTER, 90° ELBOW, 08MJIC-10MORB
16
E00494
AR
HOSE CLAMP, PLASTIC, Ø3/4”
17
8010-4P
2
QUICK COUPLER, MALE TIP, ISO 5675, 1/2" NPT
18
32L012
1
SPLIT COLLAR, Ø3/4”
19
E22743
1
EYE BOLT, Ø1/2” x 4”
20
E00495
1
FLOW CONTROL HANDLER
21
E00509-440
1
HYDRAULIC MOTOR w/ RELIEF, 255160A1912ACAAA
22
E02119
AR
HOSE CLAMP, FORMED SS
23
REF
2
HYDRAULIC HOSE, 8M3K-8FJX-8MP, 120”
24
REF
1
HYDRAULIC HOSE, 8M3K-8FJX-8FJX90S, 20”
25
REF
2
HYDRAULIC HOSE, 8M3K-8FJX-8FJX, 244”
26
REF
1
HYDRAULIC HOSE, 8M3K-8FJX-8FJX45, 41”
27
REF
1
HYDRAULIC HOSE, 8M3K-8FJX-8FJX45, 38”
28
REF
1
HYDRAULIC HOSE, 8M3K-8FJX-8FJX, 24”
29
REF
1
“TWIST” CONTROL HOSE, 8G2-8MP-8FJX, 145”
