Meyer's VB280 - Hydraulic End Gate & Related Parts

28 | P a g e M o d e l V B 2 8 0
HYDRAULIC END GATE & RELATED PARTS
KEY
PART NO.
QTY.
DESCRIPTION
1
E31055
1
FRAME WELDMENT, METER GATE
2
E31057L
1
SLIDER TUBE WELDMENT, LH SIDE
3
E31057R
1
SLIDER TUBE WELDMENT, RH SIDE
4
E00003-40
1
BELTING BAR
5
E30770
1
BELTING, GATE BOTTOM, 7-1/2” x 62-3/8”
6
E31053
1
MAIN PANEL, METER GATE
7
E31074
2
GATE CHANNEL INSERT, POLY
