Meyer's VB280 - Yoke & Clutch Hub Assembly

44 | P a g e M o d e l V B 2 8 0
YOKE & CLUTCH HUB ASSEMBLY
KEY
PART NO.
QTY.
DESCRIPTION
1
35301-1005
1
Yoke
2
23-15057
1
Wave Spring
3
38-30077
1
Overrunning Inner Hub
4
11-15081
1
Setscrew
5
12-11018
31
Ball, Ø.250
6
11-15136
1
Washer
7
24-15133
1
Retaining Ring
8
06-13492
1
Hub Clamp Assembly
9
80401-1000
1
Overrunning Hub
10
11-15134
2
Overrunning Key
11
23-15056
2
Leaf Spring
REF
38-20044
1
Yoke & Clutch Hub Assembly, Complete
