VERTICAL BEATER HEAD ASSEMBLY
KEY
PART NO.
QTY.
DESCRIPTION
1
16025
1
GEAR BOX, SRT8, 1000 RPM OPTION (SEE SEPARATE LISTING)
16025-540
1
GEAR BOX, SRT8, 540 RPM OPTION (SEE SEPARATE LISTING)
2
15764
1
RIGHT PANEL
3
15765
1
LEFT PANEL
4
16028
1
CROSS BAR
5
16030
1
LEFT BEATER
6
16031
1
RIGHT BEATER
7
3768
12
SCREW, HEX-HD, M12X35
8
4478
12
NUT, M12-8G
9
8940
4
SCREW, HEX-HD, M16X35
10
3690
4
NUT, M16-8G
11
3435
2
CIRCLIP I 80
12
7724
2
COVER PLATE
13
3462
2
O-RING, 176
14
3340
2
BEARING, 1307 E
15
7331
2
OIL SEAL, 45/72/10
16
15618
1
COVER
17
1799
6
NUT, M14-8G
18
9859
2
THREADED BAR, M14X80
19
16033
1
LUBRICATION KIT (SEE SEPARATE LISTING)
20
9114
84
SCREW, HEX-HD, M16X40
21
9569
42
KNIFE
22
9113
84
NUT, M16X1.5
REF
15730
1
VERTICAL BEATER HEAD, COMPLETE, 1000 RPM
REF
15730-540
1
VERTICAL BEATER HEAD, COMPLETE, 540 RPM
