Meyer's VB280 - Page 41

M o d e l V B 2 8 0 41 | P a g e
VERTICAL BEATER LUBRICATION KIT
KEY
PART NO.
QTY.
DESCRIPTION
1
16032
2
COPPER PLATED STEEL PIPE
2
9587
8
PIPE CLIP
3
9586
8
RIVET, Ø3.5X8
4
9578
2
FITTING
5
9579
2
COMPRESSION CONE
6
9583
2
TERMINAL, Ø1/8” GAS
7
9581
2
LUBRICATION BLOCK
8
3414
2
GREASE FITTING, MB10
9
12110
2
COMPLETE 90° TERMINAL
