M o d e l V B 2 8 0 47 | P a g e
APRON & RELATED PARTS, STANDARD 67P11 CHAIN
KEY
PART NO.
QTY.
DESCRIPTION
REF
E31110-280
2
APRON, ONE SIDE COMPLETE (46 SLATS / 292 LINKS)
1
E02024-375
1
TIGHTENER WELDMENT, RH OUTER
E02038-375
1
TIGHTENER KIT, COMPLETE, RH OUTER
2
E02040
1
TIGHTENER WELDMENT, RH CENTER
E02032
1
TIGHTENER KIT, COMPLETE, RH CENTER
3
E02031
1
TIGHTENER WELDMENT, LH CENTER
E02033
1
TIGHTENER KIT, COMPLETE, LH CENTER
4
E02037-375
1
TIGHTENER WELDMENT, LH OUTER
E02039-375
1
TIGHTENER KIT, COMPLETE, LH OUTER
5
E00234R
1
APRON BEARING ASSEMBLY, Ø2” SHAFT, RH
6
E20737-07
2
APRON BEARING ASSEMBLY, Ø2” SHAFT, CENTER
7
E00234L
1
APRON BEARING ASSEMBLY, Ø2” SHAFT, LH
8
REF
1
NUT, Ø3/4”-10, NYLOCK
9
REF
1
BOLT, HCS Ø3/4”-10, GR5
10
REF
2
BOLT, HCS Ø5/8”-11, GR5
11
REF
2
WASHER, PLAIN, Ø3/4”
12
REF
4
WASHER, PLAIN, Ø5/8”
13
REF
2
NUT, Ø5/8”-11, NYLOCK
14
REF
4
TIGHTENER NUT, Ø3/4” NYLOCK, 1137039
15
E02034
4
ROLLER, NYLON, Ø4-1/2”
16
E02035
4
COTTER PIN
17
E20728
AR
SHAFT WASHER, Ø2”
18
3465-VB560-4
2
SHAFT GUARD, REAR, 20-7/8”L
19
3465-VB750-23
1
SPACER, 3-5/16”L
20
E00225-10
96
SLAT, #67P11, 28” OAL
21
E00231-06
1
APRON SHAFT, Ø2” x 75-5/8”L
22
E00238
4
KEY, 1/2” x 1/2” x 2-1/4”L
23
E31116
4
SPROCKET, APRON, #67P11, 7 TOOTH, WELDED HUB
24
E02027
568
LINK, #67P11
25
E30810
1
TORQUE ARM / GEARBOX MOUNT
27
E31078-1
1
HYDRAULIC MOTOR SHIELD, MAIN
28
E31078-2
1
HYDRAULIC MOTOR SHIELD, FRONT
29
VB-00019-18
2
APRON SHAFT END GUARD
30
VB-00061-440
1
GEARBOX, RT350, Cod. 14552 (See Separate Listing)
31
VB-00155
1
SHAFT COLLAR, SPLIT, 8L200, Ø2”
32
VB-00181
1
KEY, 1/2" x 1/2" x 5”L
33
E00236
4
BEARING INSERT, BRASS, Ø2” SHAFT
34
E31252-3.0R
2
SPROCKET HUB SCRAPER, 3” FINGER, RH
35
E31252-3.0L
2
SPROCKET HUB SCRAPER, 3” FINGER, LH
