APRON DRIVE GEARBOX
KEY
PART NO.
QTY.
DESCRIPTION
REF
VB-00061-440
1
Gear Reducer, Complete RT350
14552
1
VB-00032-440
1
Housing
9975
2
VB-00033-440
1
Hub
14551
3
VB-00034-440
1
Circlip E 82
9918
4
VB-00035-440
1
Gear Z=49
9974
5
VB-00036-440
2
Bearing 6015
9982
6
VB-00037-440
2
Circlip I 115
9984
7
VB-00038-440
1
Pinion Z=12
8670-5
8
VB-00039
2
Key 12 x 8 x 30
4174
9
VB-00040-440
1
Gear Z=50
8670-4
10
VB-00041-440
2
Bearing 6208
3342
11
VB-00042
3
Circlip I 80
3435
12
VB-00043-440
1
Pinion Z=10
8670-3
13
VB-00044
1
Key 8 x 7 x 25
3396
14
VB-00045
1
Gear Z=43
8670-2
15
VB-00047
2
Bearing 6305
8596
16
VB-00048
2
Circlip I 62
3433
17
VB-00049
1
Pinion Z=28
8670-1
18
VB-00050
1
Bearing
1538
19
VB-00051
1
Circlip E 50
3428
20
VB-00052
2
Oil Plug Ø1” Gas
9175
21
VB-00053
2
Oil Level Indic Ø1” Glass
1831
22
VB-00054
2
Plug
8625
23
VB-00055
2
Plug
8243
24
VB-00056-440
2
Oil Seal 75/115/10
9983
25
VB-00058
1
Cover
9976
26
VB-00057-9977
1
Gasket
9977
27
VB-00059
8
Screw Hex-Hd M8 x 16
3284
28
VB-00060
1
Gasket
8671
