Meyer's VB280 - Page 55

M o d e l V B 2 8 0 55 | P a g e
HYDRAULIC SYSTEM PARTS, METERING GATE
KEY
PART NO.
QTY.
DESCRIPTION
1
E00079
4
HOSE CLAMP, PLASTIC, Ø5/8”
2
2703-LN-08
2
BULKHEAD TEE, M-JIC x3
3
E01591
2
QUICK COUPLER, 8010-4P, 1/2" NPT
4
REF
2
HYDRAULIC HOSE, 6M3K-8FJX-8MP, 120”
5
REF
4
HYDRAULIC HOSE, 6M3K-8FJX-8FJX, 258”
6
REF
2
HYDRAULIC HOSE, 6M3K-8FJX-8FJX90S, 37”
7
REF
2
HYDRAULIC HOSE, 6M3K-8FJX-8FJX90S, 14”
8
2700-LN-08
4
BULKHEAD UNION
9
6801-8-8
4
ADAPTER, 90°, M-JIC to M-ORB
10
BH287244
2
HYDRAULIC CYLINDER, Ø2.5” BORE x 48” STROKE
11
E31098
2
COVER, 2-HOLE
12
E31098-2
1
COVER, 4-HOLE
