HYDRAULIC SYSTEM PARTS, APRON DRIVE, STANDARD FLOW CONTROL
KEY
PART NO.
QTY.
DESCRIPTION
1
E30010
1
VALVE, STANDARD FLOW CONTROL, BG-514-12SAE
2
304-C-8
2
CAP, 08FJIC
3
E00509-440
1
HYDRAULIC MOTOR w/ RELIEF, 255160A1912ACAAA
6
6600-8-8-8
1
ADAPTER BRANCH TEE, 08MJIC-08MJIC-08FJS
7
6801-8-10
2
ADAPTER, 90° ELBOW, 08MJIC-10MORB
8
6801-8-12
1
ADAPTER, 90° ELBOW, 08MJIC-12MORB
9
8010-4P
2
QUICK COUPLER, MALE TIP, ISO 5675, ½” NPT
10
E00494
AR
HOSE CLAMP, PLASTIC, Ø3/4”
11
E00496-09
1
CHECK VALVE, LT-8-0
13
2700-LN-8-8
3
BULKHEAD, STRAIGHT, 08MJIC-08MJIC
14
2764-LN-8-8
1
BULKHEAD ADAPTER, 08MORB-08MJIC
15
6400-8-12
2
ADAPTER, 08MJIC-12MORB
16
E02119
AR
HOSE CLAMP, FORMED SS
17
REF
2
HYDRAULIC HOSE, 8M3K-8FJX-8MP, 120”
18
REF
1
HYDRAULIC HOSE, 8M3K-8FJX-8FJX90S, 20”
19
REF
2
HYDRAULIC HOSE, 8M3K-8FJX-8FJX, 244”
20
REF
1
HYDRAULIC HOSE, 8M3K-8FJX-8FJX45, 41”
21
REF
1
HYDRAULIC HOSE, 8M3K-8FJX-8FJX45, 38”
