Meyer SXI 720 Series - Page 55

1-800-325-9103
PB-SXI - 55 - www.meyermfg.com
KEY PART NUMBER QTY DESCRIPTION
1 901-0506 1 Bearing Standoff Weldment
2 14-0031 1 4-Bolt Flange Bearing
3 SXI-19-0214-K 1 Spline Shaft Update Kit (Prior to SN SXI19720201)
135-5050-7.5-1 1 1/2” x 1/2” x 7-1/2” Key (Prior to SN SXI19720201)
923-0517 1 Output Gearbox Jackshaft (SN SXI19720201 & Later)
4 912-0510 1 Chain Guide (Prior to SN SXI19720201)
912-0512 1 Chain Guide (SN SXI19720201 & Later)
5 25-0538 1 Second Reduction Auger Chain Brush Holder
6 929-0501 1 Extension Spring
7 933-3804 1 5/16-18 x 4” Eyebolt
925-3822-6 1 2 Chain Links
8 921-0005 2 1-1/2” Set Collar
9 910-0504-2 1 Sprocket (Prior to SN SXI19720201)
910-0511 1 Sprocket (SN SXI19720201 & Later)
10 111-0120-38 1 #120-38 Roller Chain Including Connector (Standard 11 RPM Auger)
111-0120-48 1 #120-48 Roller Chain Including Connector (7.2 RPM Auger)
11 914-0502 1 4-Bolt Flange Bearing
12 925-0532 1 Tightener Arm Assembly
13 912-0016-1 1 Nylon Roller
14 851-5013-1.5Z 2 1/2-13 x 1-1/2” Machine Bolt
15 925-0532-1 1 Tightener Arm Weldment
16 925-0532-2 1 Chain Tightener Pivot Tube Weldment
17 810-5013-Z 2 1/2” Spin Lock Nut
18 910-0502-5 4 Sprocket Drive Pin
19 851-6311-2.25Z 6 5/8-11 x 2-1/4” Hex Head Cap Screw
20 910-0529-1 1 Jackshaft Weldment (With Studs)
21 910-0502-9 1 Split Sprocket (Standard 11 RPM Auger)
910-0502-11 1 Split Sprocket (7.2 RPM Auger)
22 810-6311-Z 6 5/8” Spin Lock Nut
23 910-0529 1 Jackshaft Sprocket Assembly (Comes With Standard RPM Auger Split
Sprocket)
24 914-3824 1 Jackshaft Bearing
25 827-3816-.5 3 3/8-16 x 1/2” Knurled Set Screw
26 914-0503-1 1 Jackshaft Bearing Weldment
27 914-0503 1 Jackshaft Bearing Assembly
28 925-0528 1 Sprocket Spacer (Prior to SN SXI19720201)
925-0551 1 Sprocket Spacer (SN SXI19720201 & Later)
