KEY PART NUMBER QTY DESCRIPTION
19 851-1008-2.75Z 12 1-8 x 2-3/4” Hex Head Cap Screw
20 M1-10-0004-1-3 2 O-Beam Inner Bearing Washer
21 881-1014-2.5Z 2 1-14 x 2-1/2” Machine Bolt
22 M1-12-0017-1 1 Right O-Beam Inner Bearing Weldment
23 75-0111-3 1 O-Beam Spindle (Standard 720)
75-0118 1 O-Beam Spindle (Hi-Float Package) (Standard 865)(Optional 720)
901-0704-2-AS 1 O-Beam Spindle (720 With 4 Brake System)
See Page 92 1 O-Beam Weigh Bar Spindle (720 With Scales Only)
1 Refer to Key #8 (865 2/4 Brake System)
24 75-0111-3 1 O-Beam Spindle (Standard 720)
75-0118 1 O-Beam Spindle (Hi-Float Package) (Standard 865)(Optional 720)
901-0704-2-AS 1 O-Beam Spindle (720 With 4 Brake System)
See Page 92 1 O-Beam Weigh Bar Spindle (720 With Scales Only)
1 Refer to Key #9 (865 2/4 Brake System)
25 75-0111-3 1 O-Beam Spindle (Standard 720)
75-0118 1 O-Beam Spindle (Hi-Float Package) (Standard 865)(Optional 720)
(865 With 2 Brake System)
901-0704-2-AS 1 O-Beam Spindle (720 With 4 Brake System)
See Page 92 1 O-Beam Weigh Bar Spindle (720 With Scales Only)
1 Refer to Key #9 (865 4 Brake System)
26 See Page 78 2 Hub (Standard 720) (720 With Brakes) (720 With Scales)
See Page 78 2 Hub (Hi-Float Package) (Standard 865)(Optional 720)
975-0200 2 Hub (865 With 2/4 Brake System)
