1-800-325-9103
PB-SXI - 83 - www.meyermfg.com
KEY PART NUMBER QTY DESCRIPTION
1 925-0508 1 Gate Indicator Weldment
2 925-0519 1 Indicator Pipe (720)
925-0510 1 Indicator Pipe (865)
3 901-0500-34 1 Gate Seal Spacer
4 949-3751 1 Gate Poly
5 949-0500 2 Poly Door Slides
6 925-0504 1 Gate Cylinder Mount Weldment (Prior to SN SXI17720214)
925-0534 1 Gate Cylinder Mount Weldment (SN SXI17720214 & Later)
7 See Page 84 1 Gate Hydraulic Cylinder
8 925-0524 1 Gate Indicator Linkage Assembly (Prior to SN SXI17720213)
925-0535 1 Gate Indicator Linkage Assembly (SN SXI17720213 & Later)
9 925-3767 1 Indicator Linkage Arm Weldment
10 850-3118-2.25Z 10 5/16-18 x 2-1/4” Carriage Bolt
11 814-3118-Z 10 5/16-18 Indented Lock Nut
12 901-0553 1 Gate Weldment
To Next Page
