KEY PART NUMBER QTY DESCRIPTION
1 55-0330 2 3/8” x 80” Hydraulic Pipe (720) (Prior to SN SXI17720207)
55-0334 2 1/2” x 80” Hydraulic Pipe (720) (SN SXI17720207 & Later)
55-0328 2 3/8” x 120” Hydraulic Pipe (865) (Prior to SN SXI17720207)
55-0333 2 1/2” x 120” Hydraulic Pipe (865) (SN SXI17720207 & Later)
2 55-0328 2 3/8” x 120” Hydraulic Pipe (Prior to SN SXI17720207)
55-0333 2 1/2” x 120” Hydraulic Pipe (SN SXI17720207 & Later)
3 155-2403-08-06 1 Straight Union
4 155-6801-06-04 1 90 Degree Adjustable Elbow
5 See Page 86 1 Oiler Pump
6 155-04R17-19-1 1 1/4” x 19” Hose
7 155-2603-08-06-06 1 Tee
8 155-2403-06-06 2 Straight Union (Prior to SN SXI17720207)
155-2403-08-08 2 Straight Union (SN SXI17720207 & Later)
9 155-5406-08-06 1 Straight Reducer Bushing (Prior to SN SXI17720207)
155-2404-06-08 1 Straight Adapter Union (SN SXI17720207 & Later)
10 155-08R17-69-1 2 1/2” x 69” Hose (Prior to SN SXI17720207)
155-06R17-70-1 2 3/8” x 70” Hose (SN SXI17720207 & Later)
11 155-2404-08-06 2 Straight Adapter Union (Prior to SN SXI17720207)
155-2404-06-06 2 Straight Adapter Union (SN SXI17720207 & Later)
12 155-2500-08-06 2 90 Degree Elbow
13 55-0092 1 90 Degree Street Elbow
14 955-3753 1 Gate Cylinder Hydraulic Pipe
15 925-3754 1 Gate Cylinder Hydraulic Pipe Holder Weldment
16 955-0011-ASSY 1 Hydraulic Cylinder Assembly (Includes Key #'s 13, 14, 15, & 17)
955-0011-1 1 Cylinder Seal Kit
17 955-3605 1 3/8” 90 Degree Elbow
18 155-8010-15 2 ORB Male Tip
19 155-6400-8-8 2 Straight Connector (Prior to SN SXI17720207)
155-6400-6-8 2 Straight Connector (SN SXI17720207 & Later)
20 155-08R17-166-1 2 1/2” x 166” Hose (Prior to SN SXI17720207)
155-06R17-162-1 2 3/8” x 162” Hose (SN SXI17720207 & Later)
21 29-0029 1 Hydraulic Hose Tender Spring Kit With Sleeve & Hardware
22 811-3118-1Z 1 5/16-18 x 1” Eyebolt
23 811-3118-2Z 1 5/16-18 x 2” Eyebolt
24 805-0031-Z 1 5/16” Flat Washer
25 55-0324 2 Twin Series Clamp
26 815-3118-Z 1 5/16-18 Nylon Lock Nut
