KEY PART NUMBER QTY DESCRIPTION
1 925-0509 1 Gearbox Torque Arm Weldment
2 See Page 54 1 Second Reduction Drive
3 See Page 52 1 Berma Front Gearbox
4 See Page 50 1 First Reduction And Spinner Drive
5 923-0511 1 Adapter Shaft
6 901-0575 1 Motor To Gearbox Mount Weldment
7 See Page 98 1 Hydraulic Driven Auger Hydraulic Schematic
8 See Page 50 1 #80-116 O-Ring Roller Chain Including Connector
9 See Page 50 1 Sprocket Assembly With Hub, Bolts, & Washers
10 See Page 50 1 4-Bolt Flange Bearing
11 See Page 50 1 First Reduction And Spinner Drive
12 See Page 50 1 First Reduction And Spinner Drive
13 923-0507 1 Input Drive Shaft
14 See Page 50 2 4-Bolt Flange Bearing
