Part Designator Description MFJ Part Number
C1 Capacitor, Disc Ceramic, 50v, 20%, 22 pF 200-0018
C2,C3,C4,C6,C7,C8 Capacitor, Disc Ceramic, 25/50v, 20%, .01 uF 200-0004
C10,C33,C36 Capacitor, Disc Ceramic, 25/50v, 20%, .01 uF 200-0004
C11,C13,C14,C16,C19 Capacitor, Disc Ceramic, 25/50v, 20%, .01 uF 200-0004
C17,C18,C24 Capacitor, Disc Ceramic, 50/100v, 20%, .1 uF 200-0005
C20,C21,C25,C26,C27 Capacitor, Disc Ceramic, 25/50v, 20%, .01 uF 200-0004
C22,C23,C32,C39 Capacitor, Disc Ceramic, 25/50v, 20%, .01 uF 200-0004
C28 Capacitor, Electrolytic, Radial, 25v, 100 uF 203-0015
C29 Capacitor, Disc Ceramic, 500v, 20%, 75 pF 200-1011
C30 Capacitor, Disc Ceramic, 1 Kv, 20%, 470 pF 200-2023
C31 Capacitor, Disc Ceramic, 1 Kv, 20%, 33 pF 200-2016
C32 Capacitor, Electrolytic, Radial, 50v, 1 uF 203-0006
C38 Capacitor, Electrolytic, Radial, 35v, 220 uF 203-0019
VC1 Cap, Air Var, 6-200 pF 204-5160
D2,D3 Diode, Germanium, 1N34A 300-8001
D6 Opto, Led, 5 Mm Round, Red, MV5753 320-0001
IC1 IC, Op-amp, Quad Op-amp, 14 Pin, LM324N 311-0040
IC2 Voltage Regulator, 1 Amp, +5 Volts, 7805t 307-1011
FOR IC1 Socket, IC, Low Profile, 14 Pin 625-0031
J1 Jack, 2.1 Mm, Pcb, Dc Coaxial Jack 601-6021
J2 Connector, Header, Straight, .1, .375", 3 Pos 612-0103
JMP1-4 Wire, Jumper, 1/4"-2" 870-5000
L2 Inductor, 10mm, orange,10-403/9447, 2.64uH 402-3403
L3 Inductor, 10mm, Red, 10-402/9449, 1.8 uH 402-3402
L4 Inductor, Var, Pcm, Mc120 llow, .154 uH 402-2727
L7 Toroid, Ferrite, .5", Pre-wound, C/11, Amp 403-0020
M1 Meter, 1.5", 100 uA, SWR Meter 400-0035
Q1,Q2,Q4 Transistor, Fet, To-92, Siliconix, J310 305-6310
Q3 Transistor, Fet, Switching, VN10KM 305-6005
Q5 Transistor, HF Wide Band, NPN, 2N5109 305-0017
B1 Battery, Holder, 8-AA,Snap Connector 730-2362
FOR B1 Battery, Snap, 9v, 8" 730-3005
