MFJ-1278B MULTI-MODE APPENDIX I PARTS LIST
MFJ P/N Descrpition Component ID
TRIMPOTS, BOURNS OR EQUAL
108-6014 10 K, BOURNS 3299W-1-103 R79, R113, R114
108-7005 20 K, BOURNS 3299W-1-203 R77, R78, R106, R105,
108-7006 50 K, BOURNS 3299W-1-503 R115, R138, R139, R122
108-7008 25 K, BOURS 3299W-1-253 R119
108-7001 1 K, BOURNS 3299W-1-102 R212
TRIM POT: SINGLE TURN, MINIATURE
104-1103 10 K, Single-turn Trimmer R157, R158, R160
POT: 17MM SINGLE TURN, PCB MOUNT
104-3104 100 K LINEAR TAPER, R131
RIGHT ANGLE
CAPACITORS: MULTI-LAYER, MONOLITHIC CERAMIC
205-0010 10 PF, NPO, 10%, 50V C51
205-0100 100 PF, " C61
205-0220 220 PF, " C60, C72
205-0470 470 PF, " C59
205-1010 .001 UF, " C5
205-1015 .0015 UF, " C67
1205-1022 .0022 UF, " C54
205-1047 .0047 UF, NPO, 10% C53, C71
205
-
1147
.047 UF, X7R, 10%
C76, C80, C81, C82, C83
