MFJ-1278B MULTI-MODE APPENDIX I PARTS LIST
MFJ P/N Descrpition Component ID
201-1210 .1 UF, Z5U, 20% C1, C4, C11, C32, C21, C23
C9, C13, C14, C25, C26
C15, C17, C27, C28, C29
C30, C49, C50, C37, C38
C40, C41, C78, C43, C46
C48, C63, C66, C202, C205
C206, C208, C209, C91*
C70*, C92*, C94*, C95*
R93*, C33*
CAPACITORS: MYLAR, 50V/100V
201-0018 .01 UF, MYLAR, 5% C64#, C68#, C90#
201-0006 .022 UF, MYLAR, 5% C55, C52
201-0001 .15 UF, MYLAR, 10% C45
201-2247 .47 UF, MYLAR, 10% C89, C57
201-2233 .33 UF, MYLAR, 10% C97, C98
CAPACITORS: ELECTROLYTIC
203-0006 1 UF, 16 V, RADIAL C58, C44
203-0002 2.2 UF, 16V, RADIAL C65
203-0012 10 UF, 16 V, RADIAL C3, C6, C7, C22, C8, C18
C201
203-0014 47 UF, 16 V, RADIAL C10, C31, C203, C204, C99
203-0003 100 UF, 16 V, RADIAL C16
203-2100 1000 UF, 25 V, AXIAL C12
203-0004 470 UF, 16 V, RADIAL C75
