MFJ-1278B MULTI-MODE APPENDIX I PARTS LIST
MFJ P/N Descrpition Component ID
CAPACITOR: OTHER TYPES
203-8010 1 UF, 16 V, RADIAL C20
TANTALUM TYPE
204-0060 60 PF, TRIMMER C47
(2 LEADS, .20" SPACING)
IC SOCKETS: LOW PROFILE
625-0184 8-PIN SOCKET U8
625-0031 14-PIN SOCKET U2, U3, U4, U7, U9, U10
U11, U13, U14, U20, U30
U31, U37, U41, U201
525-0030 16-PIN SOCKET U1, U12, U16, U26, U29
U32, U33, U34, U35, U36
625-0291 20-PIN SOCKET U5, U15, U27, U28, U38
U39, U40
625-0292 28-PIN SOCKET U6, U25
625-0132 32-PIN SOCKET #U23, U24
625-0181 40-PIN SOCKET U21, U22
IC'S
311-0358 LM358, Dual Op-AMP U8
311-0004 LM348N, QUAD OP-AMP U3
311-0040 LM324N, QUAD OP-AMP U201
311-1556 LM556CN, OSC/TIMER U2
311-2045 XR2206CP, FSK GENERATOR, U16
