MFJ-1278B MULTI-MODE APPENDIX I PARTS LIST
MFJ P/N Descrpition Component ID
310-3138 74HC138, 3-to-8 LINE DECODER U29#, U12#
310-0054 4053B, TRIPLE 2-CH U26, U35, U36
CMOS ANALOG SWITCH
310-0053 4052B, DIFFERENTIAL U32, U33, U34
4-CH CMOS ANALOG SWITCH
310-0040 4066, QUAD CMOS SWITCH U30, U31
310-3021 74HCT21, DUAL 4-INPUT AND U41*
310-3273 74HCT273, QUAD D FLIP FLOP U40
DIODES/LEDS
301-0012 1N754, 6.8 V ZENER CR6, CR8
301-1004 1N4001, 1A RECTIFIER CR22, CR7, CR2, CR3, CR4
CR5
301-1005 1N4006, 1A RECTIFIER CR27, CR28
301-0003 1N4148, SWITCHING CR9, CR10, CR11, CR13
CR15, CR14, CR24, CR16
CR23, CR29, CR30, CR201
CR202, CR32, CR25, CR26
301-1015 1N4746, 18 V ZENER CR1
301-5257 1N5257B, 33 V ZENER CR12, CR31
320-0001 RED LED, 5 MM ROUND CR17, CR19, CR18, CR33
320-0003 YELLOW LED, 5 MM ROUND CR20
320-0002 GREEN LED, 5 MM ROUND CR21
TRANSISTORS:
