MFJ-1278B MULTI-MODE APPENDIX I PARTS LIST
MFJ P/N Descrpition Component ID
305-0001 2N3904, GENERAL PURPOSE NPN Q9, Q1, Q2, Q4, Q6, Q7
Q22, Q15, Q13,Q14, Q16
Q19
305-0002 2N3906, GENERAL PURPOSE PNP Q8, Q5, Q12, Q21, Q23
305-2006 MPS-A92 Q18
VOLTAGE REGULATOR
307-2006 7805CT, TO-220, +5 VOLTS Q3
CONNECTORS
612-1010 10-PIN, .1 CENTER, RIGHT J5#
ANGLE MALE HEADER, 22-05-3181
612-0032 2-PIN, .1 CENTER, MALE JMP4, JMP5, JMP7, JMP8,
HEADER, MOLEX 22-03-2021 JMP10, JMP13, JMP 16(2)
OR EQUAL JMP 23*, JMP A, JMP E
JMP F, JMP G, JMP H
JMP J, JMP K, JMP L
JMP R
612-0033 3-PIN, .1 CENTER, MALE JMP1, JMP9, JMP14,
HEADER, MOLEX 22-03-2031 JMP18*, JMP19*(2)
OR EQUAL JMP22*, JMP24*
612-0035 5-PIN, .1 CENTER, MALE J14
HEADER, MOLEX 22-03-2051
OR EQUAL
612-0036 6-PIN, .1 CENTER, MALE J15*
HEADER, MOLEX 22-03-2061
612-0036 20-PIN, .1 X .1 CENTER, J4
MALE HEADER,
611-1005 5-PIN, DIN FEMALE, PC MT., J2, J9
RIGHT ANGLE, SWITCHCRAFT
