Fuse Replacement
157
5
Main fuse box fuse specifications
Fuse number Rating (AMPS) Circuit protected
115AHorn
220AWindow - RH rear
3 10A Rear fog guard lights
4 20A Window - LH rear
5 10A Interior & luggage compartment lights, Seat belt buckle - RH, Audio unit, Door mirrors, Clock
620AWindow - LH front
7 30A Sunroof
8 20A Window - RH front
9 20A Screen washers, Headlight washers
10 10A Headlight - RH main beam
11 10A Daylight running lights, Interior illumination (Scandinavia)
12 10A Headlight - LH main beam
13 10A Side & tail lights - LH, Headlight levelling - LH, Glovebox light, Clock, Interior lights
14 10A Headlight - RH dipped beam
15 10A
Side & tail lights - RH, Headlight levelling - RH, Number plate light
16 10A Headlight - LH dipped beam
17 20A Blower motor
18 20A Seat heaters
19 10A Audio system
20 10A Engine starting
21 15A Windscreen wipers - front
22 10A Door mirrors
23 10A Anti-lock braking system
24 10A Brake lights, Reversing lights
25 10A Anti-theft alarm, Blower motor, Direction indicators, Clock, Instrument pack
26 15A Rear screen wiper, Headlight washers, Air conditioning illumination, Seat heaters
27 5A Airbag SRS
