Heating & Ventilation
35
1
Heating & Ventilation
VENTILATION
The heating and ventilation system provides fresh or heated air to
the interior of the car from the air intake grille in front of the
windscreen.
NOTE: Always keep the air intake grille clear of obstructions such as
leaves, snow or ice.
Air outlets are provided to the windscreen, face and feet - the
location of those vents is shown in the illustration above.
Centre face level vents
Rotate the thumbwheel up to open, or down to close the vents.
Direct the air flow by moving the control in the centre of the
louvres up and down, or from side to side.
Use the air flow lever to open or close the heater bypass.
HB0247b
HB0079
