Technical Data
185
6
TOWING WEIGHTS
NOTE: The maximum towing weights shown are to an industry defined standard and represent the maximum weight that can be towed by the car, allowing
it to restart efficiently on a 12% gradient at sea level. Any extra weight, such as luggage and/or passengers should be deducted from the maximum towing
weight.
1.1 1.4 1.6 1.8 1.8 - 160 2.0 Diesel
Max. trailer weight (unbraked) kg 500 500 500 500 500 500
Max. trailer weight (braked) kg 700 1000 1000 1000 1000 1000
Max. nose weight (Tow hitch downward load)
†
kg 70 70 70 70 70 70
Max. roof rack load kg 65 65 65 65 65 65
Gross train weight = maximum laden vehicle weight + maximum trailer weight
†
To increase stability, it is recommended that you adjust the nose
weight to the maximum limit, when loading to the maximum trailer weight
