3.3 Dimensions HS + Calorifier Below (Additional information available from the website www.mhgheating.co.uk)
Legend
VL Hot water Primary Flow 1” RL
Hot Water Primary Return 1”
WW Hot Water Secondary Outlet ¾” A 120 Litre Calorifier
Z Hot Water Secondary Return ½” B Pipework Cover
KW Cold Water Secondary Inlet ¾” C Calorifier Cover
3.3 Dimension
s HS + Calorifier Adjacent (Additional information available from the website www.mhgheating.co.uk)
Legend
RL Hot Water Primary Return ¾” VL
Hot water Primary Flow ¾”
WW Hot Water Secondary Outlet ¾” D 60 Litre Calorifier
KW Cold Water Secondary Inlet ¾” E Calorifier Cover
Z Hot Water Secondary Return ½” F Pipework Cover
