MicaSense RedEdge User Manual

PAGE 9
Start processing your images
Transform your raw data using MicaSense Atlas
Upload your data to the Atlas cloud
Use the MicaSense Uploader, found under ‘Downloads’ in your ATLAS
account.
Create your farms and elds
Draw your eld boundary to easily organize and store your data.
Review your outputs
When processing is complete, view your outputs from any connected
device.
Let ATLAS process your data
Once you have created your elds and your upload is complete, Atlas will
process your data, typically within 24 hours.
To learn more about Atlas or to start a free trial, please visit
micasense.com/atlas

MicaSense RedEdge Specifications

General

Spectral Bands	Blue, Green, Red, Red Edge, NIR
Band Central Wavelength	Blue: 475nm, Green: 560nm, Red: 668nm, Red Edge: 717nm, Near Infrared: 840nm
Bandwidth	Blue: 20 nm, Green: 20 nm, Red: 10 nm, Red Edge: 10 nm
Image Resolution	1280 x 960 pixels per band
Capture Rate	1 capture per second
Field of View	47.2° HFOV
Power Requirements	7-25 V DC
Sensor	5 individual sensors
Interfaces	Serial, Ethernet
Operating Temperature	0-50° C
Storage Temperature	-20-60° C
DLS	Integrated Downwelling Light Sensor (DLS)
Sensor Type	Global Shutter CMOS
