SF52 User’s Manual
Michell Instruments 11
APPENDIX A
A.1 Dimensions
G1/2” BSP bonded seal
Ø28.65 x 2.61mm
(Ø1.12 x 0.10”)
Figure 9 Dimensions - SF52
SECTION ON A-A
35.0H11
O
26.8 O
12 O
14.3
3
70
39
40 O
45
49
15.0
2.2
19.5
19.0
O
28
3
M24 x 1.5-7H
(LOOSE FIT)
2 OFF
TAP M6 x 5 FTD
1 x 45 v
BOTH ENDS
TAP 1/8" BSP
TAP 1/4" BSP
3.2
3.2
3.2
3.2
A
A
TAP 1/2" BSP x 18.0 DEEP
MINIMAL CHAMFER LEAD-IN
TO REMOVE SHARP EDGES
100
28
O
40 20.0
30
19
20
Figure 10 Dimensions - G½" BSP Sample Block
Ø 39mm
(Ø 1.5”)
19mm
(0.75”)
20mm
(0.79”)
20mm
(0.79”)
100mm
(3.9”)
40mm
(1.6”)
30mm
(1.2”)
Ø28mm
(Ø1.1”)
TAP 1/4” BSP
Figure 11 Dimensions - G½" BSP Sample Block with Filter
