Update Documentation P341/EN AD/F43
MiCOM P341 (AD) -17
Opto Coupled Binary Inputs
(Opto Config)
Global Nominal V:
24 - 27V
30 - 34V
48 - 54V
110 - 125V
220 - 250V
Custom
Opto Input 1:
(up to):
Opto Input #. (# = max. opto no. fitted):
Custom options allow independent
thresholds to be set per opto, from the same
range as above.
Opto Filter Control:
Binary function link string, selecting which
optos will have an extra 1/2 cycle noise filter,
and which will not.
Characteristics:
Standard 60% - 80%
50% - 70%
Control Inputs into PSL
(Ctrl. I/P Config.)
Hotkey Enabled:
Binary function link string, selecting which of
the control inputs will be driven from
Hotkeys.
Control Input 1: Latched/Pulsed
(up to):
Control Input 32: Latched/Pulsed
Ctrl Command 1:
(up to):
Ctrl Command 32:
ON/OFF
SET/RESET
IN/OUT
ENABLED/DISABLED
IED Configurator
Switch Conf. Bank: No Action/Switch Banks
IEC 61850 GOOSE
GoEna: Disabled/Enabled
Test Mode: Disabled/Pass Through/Forced
VOP Test Pattern: 0x00000000...
0xFFFFFFFF
Ignore Test Flag: No/Yes
Control Input User Labels
(Ctrl. I/P Labels)
Control Input 1:
(up to):
Control Input 32:
User defined text string to describe the
function of the particular control input
Settings in Multiple Groups
Note: All settings here onwards apply for
setting groups # = 1 to 4.
Protection Functions
System Config.
Phase Sequence: Standard ABC/Reverse
ACB
VT Reversal: No Swap/A-B Swapped/B-C
Swapped/C-A Swapped
CT Reversal: No Swap/A-B Swapped/B-C
Swapped/C-A Swapped
Reverse/Low Forward/Over Power
Operating mode:
Generating
Motoring
Power 1 Function:
Reverse
Low forward
Over
-P>1 Setting (reverse power/P<1
Setting (Low forward power)/ P>1
Setting (Overpower):
4…300.0W (1A, 100V/120V)
16…1200.0W (1A, 380V/480V)
20…1500.0W (5A, 100V/120V)
80…6000.0W (5A, 380V/480V)
Equivalent Range in %Pn 2%…157%
Power 1 Time Delay: 0.00…100.0s
Power 1 DO Timer: 0.00…100.0s
P1 Poledead Inh: Disabled/Enabled
Power 2 as Power 1
Sensitive/Reverse/Low
Forward/Overpower
Operating mode:
Generating
Motoring
Sen Power1 Func:
Reverse
Low forward
Over
Sen -P>1 Setting (Reverse Power)/Sen <P
Setting (Low Forward Power)/Sen >P Setting
(Over Power):
0.3…100.0W (1A, 100/120V)
1.20…400.0W (1A, 380/480V)
1.50…500.0W (5A, 100/120V)
6.0…2000.0W (5A, 380/480V)
Equivalent range in %Pn 0.5%…157%
Sen Power 1 Delay: 0.00…100.0s
Power 1 DO Timer: 0.00…100.0s
P1 Poledead Inh: Disabled/Enabled
Comp angle C: -5…+5.0
Sen Power2 as Sen Power 1
