7
©2020 Micro-Air, Inc. May 1, 2020 Revision 1.04
Operation
Image Icons
Image icons are displayed on your screen as touch/press areas. A complete list of them is provided in
Appendix I of this document. They are organized to show related icons with functions described in the
text below.
Basic operations
Cool, heat strip, heat pump, and furnace
aqua modes are available based on system
configuration. Press the image icon to select a different operating mode.
Automatic modes switch between cooling and the
to maintain temperature. These modes are available based on the heating modes
offered by your system.
Fan speed can be selected between low
automatic. Automatic changes fan speeds as required for improved comfort.
Home, away, and schedule modes provide three different thermostat experiences.
Home mode is the traditional way a thermostat operates, changing at a specific set
point. Away mode provides two set points allowing a wider range of temperatures.
Schedule mode allows changing the temperature up to four times each day.
Adjusting the brightness
The display automatically dims after 25 seconds without a touch. There are two dimming modes
selectable for this feature. Day mode shows the screen but at a dimmer setting. Night mode shows only
a small logo with the rest of the screen black. Brightness adjustment is available for both modes.
Using the schedule
Schedule entries must be created before using the schedule. Press the power icon to turn the
control off then press the schedule icon. Set up to four times and temperature changes in the change
area under the 12/24-hour selection. --:-- indicates not enabled. Press the time or --:-- and a blue box
will appear over the value. Use the up and down arrows to make the adjustment. Press the power icon
The power button icon on the top right of the thermostat turns the system off and on.
Additional settings and scheduled temperature changes are available when the
thermostat is off.
