dsPIC33/PIC24 Family Reference Manual
DS30009711C-page 12  2006-2019 Microchip Technology Inc.
Table 4-1: Selectable Input Sources (Maps Input to Function)
Input Name
(1)
Function Name Register Bits
Configuration
Bits
External Interrupt 1 INT1 RPINR0<13:8> INT1R<5:0>
External Interrupt 2 INT2 RPINR1<5:0> INT2R<5:0>
External Interrupt 3 INT3 RPINR1<13:8> INT3R<5:0>
External Interrupt 4 INT4 RPINR2<5:0> INT4R<5:0>
Timer2 External Clock T2CK RPINR3<5:0> T2CKR<5:0>
Timer3 External Clock T3CK RPINR3<13:8> T3CKR<5:0>
Timer4 External Clock T4CK RPINR4<5:0> T4CKR<5:0>
Timer5 External Clock T5CK RPINR4<13:8> T5CKR<5:0>
Input Capture 1 IC1 RPINR7<5:0> IC1R<5:0>
Input Capture 2 IC2 RPINR7<13:8> IC2R<5:0>
Input Capture 3 IC3 RPINR8<5:0> IC3R<5:0>
Input Capture 4 IC4 RPINR8<13:8> IC4R<5:0>
Input Capture 5 IC5 RPINR9<5:0> IC5R<5:0>
Output Compare Fault A OCFA RPINR11<5:0> OCFAR<5:0>
Output Compare Fault B OCFB RPINR11<13:8> OCFBR<5:0>
UART1 Receive U1RX RPINR18<5:0> U1RXR<5:0>
UART1 Clear-to-Send U1CTS
RPINR18<13:8> U1CTSR<5:0>
UART2 Receive U2RX RPINR19<5:0> U2RXR<5:0>
UART2 Clear-to-Send U2CTS
RPINR19<13:8> U2CTSR<5:0>
SPI1 Data Input SDI1 RPINR20<5:0> SDI1R<5:0>
SPI1 Clock Input SCK1 RPINR20<13:8> SCK1R<5:0>
SPI1 Slave Select Input SS1
RPINR21<5:0> SS1R<5:0>
SPI2 Data Input SDI2 RPINR22<5:0> SDI2R<5:0>
SPI2 Clock Input SCK2 RPINR22<13:8> SCK2R<5:0>
SPI2 Slave Select Input SS2
RPINR23<5:0> SS2R<5:0>
Note 1: The device may have more or less number of input functions. For actual details, please refer to the
specific device data sheet.
