ENGLISH
DESCRIPTION OF CHARACTERISTICS AND OPERATION
The "MP2-HT mA" dosing pumps series are ideal for the most varied treatments.
They can operate in Manual, mA and the flowrate is adjustable from 10% to 100% of the maximum flowrate. They can
adjust the flowrate by varying the rotation speed of the roll holder.
Optionally, these pumps can be equipped with a peristaltic tube break sensor which, in case of chemical leaks, blocks the
dosage and they can optionally have a relay output, configurable for the repetition of an alarm (for example: flow alarm,
level alarm, peristaltic hose breakage alarm, etc).
FRONT PANEL DESCRIPTION
1.Display LCD 16 x 2 backlight
2.Green Led: ▪ fix = PUMP ON
▪ blinking = PUMP IN ALARM
3.Red Led: indicates the injections of chemical dosing
4.ENTER/MENU button : ▪ allows to enter in programming
▪ saves the changes
5. ESC/SBY button: ▪ allows to exit from the menu
▪ puts the pump in stand_by mode
6/7. ▲▼ buttons : ▪ allow to navigate through the menu
▪ allow to modify the parameters values
8. Prime button: ▪ allows to prime the pump
GENERAL FUNCTIONS
- VISUALIZATION OF DOSING TYPE
- REAL TIME FLOW RATE% VISUALIZATION
- 2 POSSIBLE TYPES OF DOSING: MANUAL, mA
- MENU IN 4 LANGUAGES: ITALIAN, ENGLISH, FRENCH, SPANISH
- POSSIBILITY TO INSERT A PASSWORD
- DELAY ON SWITCHING ON
- PRIME BUTTON
- ALARM RELAY (DRY CONTACT) OUTPUT FOR REPEATING ALARMS
- RESTORATION OF DEFAULT PARAMETERS
- DOSAGE STOP (STAND_BY)
- CONTROL OF PRODUCT END LEVEL
- ENABLE INPUT SIGNAL
- HOSE BREAKAGE SENSOR
