GPIOPinAssignments
Pin# Description
1 Ground
2 GCK0DedicatedspecialpurposeLVTTL
input–Leaveunconnected
3 GPIO[6]
4 GPIO[0]
5 GPIO[7]
6 GPIO[1]
7 GPIO[8]
8 GPIO[2]
9 GPIO[9]
10 GPIO[3]
11 GPIO[10]
12 GPIO[4]
13 GPIO[11]
14 GPIO[5]
TheGTadapterhasatotalof12generalpurposeI/Osignals(GPIO[0]toGPIO[11]).Bydefaultonpower
upallGPIOsignalsareconfigured asinputs(directioncontrol=0).RefertotheserialAPIdocumentation
fordetailsonconfiguringandusingGPIOsignals.
WARNING:TakecarewhenconnectingtoGPIOsignals topreventdamagetotheserialcard.Outputs
shouldonlybeconnectedtoinputsandnototheroutputs.Voltagelimitsasshownaboveshouldnotbe
exceeded.
