2).Main functions
Brightness, contrast, talk volume, color and display mode adjustable.
Real-time monitoring of door station or CCTV camera
“Do not disturb” function
Broadcast and intercom call to other monitors
Monitor listening to other indoor monitors
Call transfer to other indoor monitors
Lock control
5、Package contents
U
se
r m
a
una l
User manual
Wall bracket
2*Expansion bolt
2x5 pin connector
(red/blue/yellow/
white/brown)
4 pin connector
(red/blue/yellow/
white)
4 pin connector
(white/blue/
white/blue)
Monitor
Desiccant
2*M5*30
fixing screws
Adaptor
6、System layout
The port 2 connect to door station
The system can support maximum1 master monitor, 3 sub monitors, 2 door
stations and 8 CCTV cameras.
Door 1
Door 2
Master monitor
Sub Monitor
Sub Monitor
Sub Monitor
CCTV1
CCTV1
CCTV1
CCTV1
CCTV2
CCTV2
CCTV2
CCTV2
