micron_xccela_zedboard_user_guide.pdf Rev 2.1 4/19 3
Micron
®
Xccela
™
Flash User Guide for ZedBoard
™
1 Introduction
The ZedBoard is an evaluation and development board based on the Xilinx Zynq™-7000 All
Programmable SoC (AP SoC). Combining a dual Cortex-A9 processing system (PS) with 85,000
Series-7 programmable logic (PL) cells, the Zynq-7000 AP SoC can be targeted for broad use in
many applications. The ZedBoard’s mix of on-board peripherals and expansion capabilities make it
an ideal platform for both novice and experienced designers. The features provided by the
ZedBoard consist of the following:
Xilinx® XC7Z020-1CLG484CES
Zynq-7000 AP SoC
Primary configuration = QSPI flash
Auxiliary configuration options:
-
Cascaded JTAG
-
SD card
Memory
-
512MB DDR3 (128M x 32)
-
256Mb QSPI flash
Interfaces
-
USB-JTAG programming using Digilent SMT1-equivalent circuit
-
Accesses PL JTAG
-
PS JTAG pins connected through PS Pmod
-
10/100/1G Ethernet
-
USB OTG 2.0
-
SD card
-
USB 2.0 FS USB-UART bridge
-
Five Digilent Pmod™ compatible headers (2x6) (1 PS, 4 PL)
-
One LPC FMC
-
One AMS header
-
Two reset buttons (1 PS, 1 PL)
-
Seven push buttons (2 PS, 5 PL)
-
Eight dip/slide switches (PL)
-
Nine user LEDs (1 PS, 8 PL)
-
DONE LED (PL)
Onboard Oscillators
-
33.333 MHz (PS)
-
100 MHz (PL)
Display/Audio
-
HDMI output
-
VGA (12-bit color)
-
128x32 OLED display
-
Audio line-in, line-out, headphone, microphone
Power
-
On/off switch
-
12V @ 5A AC/DC regulator
