SmartFusion2 DMPM Kit

Kit Contents – SF2-DMPM-KIT

Kit Contents – SF2-DEV-KIT

Table 1 • SF2-DMPM Daughter Board Kit Contents

Quantity Description

SF2-DMPM Daughter Card

1 12 V, 5 A AC Power Adapter

1 Any Plug to Grounded 3 pin UK/Hong Kong Plug Adapter

1 Enhanced USB I

C Module

1 USB CABLE A-B 3'

50 Mini Jumpers

1 SF2-DMPM-Kit Quickstart Card

Table 2 • SF2-DEV-KIT Contents

Quantity Description

1 SmartFusion2 Development Board with M2S050T-FGG896

1 12 V, 6 A AC Power Adapter

1 FlashPro4 Programmer

1 USB A to MicroB Cable

1 USB MicroA to A Cable

50 USB A to Mini-B Cable

1 PCI Edge Card Ribbon Cable

Figure 2 • SF2-DMPM Daughter Board with the SmartFusion2 Development Kit Board
