adjust_pps
Manually adjust the sub-second time of the system when in manual time
mode.
steer_frequency
Manually change the frequency of the instrument's outputs.
steer_phase
Manually change the phase of the instrument's outputs
GPS Commands
latitude
Sets latitude, Default [N], option [S] or [-].
longitude
Set longitude. longitude <degrees> [E](default) or [W]
altitude
Set Antenna altitude Default units = [m]meters, optional [ft] feet
fix_position
Sets a static location based on current GPS determined position location
or it allows the operator to enter the latitude, longitude, and altitude.
[current] or [<latitude> <longitude> <altitude>]. Default = Current.
position_period
Set GPS auto-positioning period. position_period <period>
[h]ours(default) or [m]inutes.
position_mode
Set GPS position mode. position_mode [auto|manual|dynamic]
antenna_delay
Sets GPS antenna delay in seconds.
antenna_voltage
Set GPS antenna voltage (0,5,12)
mask_angle
Set mask angle. mask_angle <degrees>
datum
Set GPS datum, Default = wgs84, option nad83
gps_tracking_timeout
Set GPS tracking lost timeout in seconds.
Logging Commands
log_interval
Sets the GPS logging interval for ftp files, in minutes log_interval
<interval in minutes> [1-1400]
log_number
Sets the maximum number of GPS ftp log files. log_files <number>
log_compression
Enable or disable GZIP compression for the ftp log files. 0=Off 1=On
log_filename
Set name pattern of log files log_filename <user|timestamp>
Timestamp – files are named based on the date/time they were created
with an optional suffix. User – Users supplies file prefix name, Unique
ID, and suffix for the filename.
log (ftp|rt) [type].
Add a GPS log. User must specify if the log is for ftp or real time (rt)
logs, and the log type desired from the Novatel receiver.
unlog (ftp | rt) [type]
Clear specified GPS logs. unlog (rt|ftp) [type]
Default = all logs.
log_enable (ftp|rt)
Enable or disable GPS logging, Specify ftp or real time (rt) then off|on.
0=Off, 1=On
list_logs (ftp|rt).
Lists the user gps logging settings for the ftp or real-time (rt)
configuration files. If there are no files listed the 4380A is using the
factory default settings.
save_logs (ftp|rt).
Save GPS logging settings to disk. logs_save (rt|ftp) <filename>.
Default = <default>.
load_logs (ftp|rt).
Restore the ftp or rt user logging configuration settings from file(s) on
the disk
delete_logs (ftp|rt)
Deletes specified user ftp|rt logging configuration files.
Reference Commands
reference
Indicates which frequency reference to use (internal | external |
timescale)
reference_type
Indicates which frequency reference is providing the external reference
input (cesium | hp5071a | maser)
steer_source
Sets the phase measurement source (gps | manual)
Hardware Output Commands
irig
Allows the operator to set the IRIG codes on the 4394A (DC IRIG) and
4387A (AM IRIG) Cards.
irig_input
Allows the operator to set the IRIG input codes on the 4383A IRIG
input Card.
