3.4.1.1 Real Time Data Port (1135)
Certain applications require that GPS data be retrieved in a timely manner. For this purpose, Port 1135
may be configured to provide real-time data output. Users can specify which logs are output and users may
request any of the ASCII logs specified in the user manual for the Novatel OEM6 receiver
(http://www.novatel.com/support/info/documents/). See the log command.
3.4.1.2 Command Port (1700)
System commands can be issued to the 4380A via the command port. These commands provide a limited
set of operations to be used for remote control of the system. Typically, a remote monitoring station may
record an error that indicates user intervention is required. The remote monitoring station would then be
able to access the command port via the Ethernet and issue the commands required for recovering from the
error. The following list provides a short description of each command.
Note: All commands are in lowercase and the commands are case sensitive.
Command
Description
Basic Commands
help, h or ? <command>
Display help for a command or list all commands. Proper format is to
proceed the command with help, h, or ? help <command>
quit
Closes the command connection and terminates the telnet connection.
Status Commands
show
Shows the current system factory (config), user configuration (settings),
network (network), and system status (status) values. This command is
the equivalent of sending these 4 commands at the same time.
status
Shows the values of all runtime status variables
alarm
Shows the current alarm state
alarms
Shows active alarms
config
Shows unit configuration parameters
network
Show network interface configuration. Note: These settings do not
apply if the mode=DHCP.
syslog
Dump the system log file.
diag
Adjust diagnostic logging levels.
diag_port
Switch to the diagnostic port (1800).
ptdavg_port
Switches the command port display to port 2100 to view the average
measurement results.
ptdraw_port
Switches the command port display to port 2101 to view the raw
measurements every second.
status_port
Switch to the status port (1900)
Settings
settings
Shows the current user control/configuration settings.
diff
Displays any difference between the current system settings and the
saved user configuration file.
load
Restore system configuration settings from a file on the disk
save
Save current configuration settings to disk. save <filename>. Default =
<default>
list
List available user configuration files available on disk. If there are no
files listed the 4380A is using the factory default settings.
delete
Deletes specified user system configuration files.
Manual Time Setting
Commands
force time
Manually set the time and enable outputs when GPS is not available
adjust_time
Manually adjust the time in 1 second increments when in manual time
mode
