Gigabit Ethernet Switch – Quick Installation Guide Page 3 of 9
_______________________________________________________________________________________________
©2017_MICROSENS GmbH & Co. KG_Küferstr. 16_59067 Hamm/Germany_www.microsens.com
Table 3: Port Status LEDs
1.5 Mode / Reset Button
By pressing the mode / reset button for certain period of time, users can perform the
following tasks.
 Change Port Status LED Mode to read the port status correctly in the two
different modes (link/act/speed mode or PoE mode).
 Reset the Switch to reboot and get the switch back to the previous configuration
settings saved.
 Restore the Switch to Factory Defaults to restore the original factory default
settings back to the switch.
Note: According to the table below, users can easily judge which task is being per-
formed by reading the LED behaviors while pressing the mode / reset button.
Once the LED behaviors are correctly displayed, users may just release
the button.
Table 4: Mode / Reset Button Descriptions
When PoE Mode LED Lit
LED
Color
State
Description
RJ45
Ports
Green
On
The port is enabled and supplying power to connected
device.
Amber
On
An abnormal state, such as overload status, has been
detected in the switch.
--
Off
The port has no active network cable connected, or it is not
connected a PoE PD device. Otherwise, the port may have
been disabled through the switch user interface.
Task to be
Performed
Time Period of
Pressing Button
SYS LED
Behavior
Port Status LED
Behavior
Change LED Mode
0 ~ 2 seconds
On green
LED status will be
changed according the
mode selected.
Reset the switch
2 ~ 7 seconds
Blinking green
ALL LEDs light OFF
Restore to defaults
7 ~ 12 seconds
Blinking green
ALL LEDs stay ON
