Set by highlighting the parameter with the and navigation keys, then
altering the setting in pre-determined steps with the and navigation
keys, or by finer increments using the data entry keypad. The range is:
20Hz to 200KHz (6375)
20Hz to 500KHz (6376)
20Hz to 1MHz (6377)
20Hz to 5MHz (6378)
20Hz to 10MHz (6379)
Toggles between auto range and manual range selection, set by highlighting
the parameter with the and navigation keys and altering the setting
with the and navigation keys. Auto range automatically selects the
most accurate range for the measurement. Circumstances where manual
ranging may be more appropriate include:
measuring non-linear components (auto range may hunt)
to avoid the short auto range delay, for example when using max speed
with an auto handler.
The manual range is set using the data entry keypad. Ranges 1 to 7 are
valid.
Four measurement speeds are available: Slow, Med, Fast and Max.
Selecting slower measurement speeds increases the display resolution and
decreases measurement noise by averaging. The measurement speed is set
by highlighting the parameter with the and navigation keys and altering
the setting with the and navigation keys.
For detail description of measurement speed, refer to chapter 6-
specification.
