APPENDIX B Test Range and Functions
Item Symbol Test range Error range Minimum test
voltage
Resistance
R
0-1Ω
±10%
R
>1Ω && <10Ω
±5%
R
>10Ω && <100Ω
±2%
R
>100 && <1KΩ
±2%
R
>1KΩ && 10KΩ
±2%
R
>10KΩ && <100KΩ
±2%
R
>100KΩ && 1MΩ
±2%
R
>1MΩ && <20MΩ
±2%
Capacitance
C
0~10pF
±20%
C >10 pF && <20pF ±10%
C
>20Pf && <3.0uF
±5%
Conduction COND
0.1Ω ~ 50.0Ω
±1%
Insulation
resistance
IS
1MΩ ~ 1.99MΩ
±10%
50V
IS
2.00 MΩ ~ 4.99 MΩ
±10% 50V
IS
5.00 MΩ ~ 9.99 MΩ
±10%
50V
IS
10.00 MΩ ~ 19.99 MΩ
±10% 50V
IS
20.00 MΩ ~ 49.99 MΩ
±10%
50V
IS
50.00 MΩ ~ 99.99 MΩ
±10% 100V
IS
100.0 MΩ ~ 199.9 MΩ
±10%
200V
IS
200.0 MΩ ~ 499.9MΩ
±20% 500V
IS
500 MΩ ~ 1000.0MΩ
±20%
1000V
Diode D 0.6 ~ 6.8V ±25%
>=7.0V
---
Short circuit
determination
value
O/S
2KΩ ~ 100KΩ
±10%
Intermittence test
20Ω ~ 2KΩ
±10%
Unilateral test 1pF~999pF ±20%
HIPOT current
leakage
0.02mA~0.0499mA
±50%
0.05mA~0.099mA ±20%
0.1mA~0.199mA
±20%
