80
0.2mA~0.499mA ±20%
0.5mA~4.99mA
±10%
APPENDIX C Technical Specifications
Advanced functions
Programmable continuous testing
Automatic pin search
Self-diagnosis
Self-calibration offset
Basic accuracy
±5%
Test scan mode Switchable automatic/short circuit scan
Test signal source
Low voltage test signal
Rated output
5Vdc
±5% accuracy
DC insulation/AC tolerance
test range
8751/8761-FA 50~1500VDC / 100~1000VAC
8751/8761-NA
50~1000VDC / 100~700VAC
8751/8761-NAC 50~1000VDC / 100~700VAC
8751/8761-N
50~1000VDC / -----------------
50V Resolution
High voltage output accuracy
±5% accuracy
Display/sound device 320x240 resolution graphic LCD display
6 digit digital display digit
Pass/Fail LED red green indicator/screen
display/sound
Test pin
A maximum of 256 independent test pins
64/128/256 pin selection
High voltage calibration positive and negative
output
Automatic pin search terminal
Control panel
System/quick/edit/function button group
Interface RS-232 communication port (only for future
connection software use)
Printer port
