Page #19 background image
MICROSCANNER
ENGLISH - 19
Technical Specifications
Dimensions:
MICROSCANNER :
13.97 cm x 8.25 cm x 2.54 cm (5.5" x 3.25" x 1")
Wiremap Adapter:
7.62 cm x 3.18 cm x 2.11 cm (3" x 1.25" x .83")
Office Identifier:
7.62 cm x 1.60 cm x 1.47 cm (3" x .63" x .58")
Coax Adapter:
7.62 cm x 1.60 cm x 1.47 cm (3" x .63" x .58")
Ground pin receptacle size: 2.03 mm (.08")
Weight:
MICROSCANNER : 171.54 g (.38 lbs)
Wiremap Adapter/Office Identifier: 9.03 g (.02 lbs)
Power Source: 9 V Alkaline battery
User Interface:
Display: Custom LCD
Size: 4.42 cm x 2.15 cm (1.75" x .85")
Keypad: Four momentary contact keys
Environmental:
Operating Temperature:0° to 50°C (32° to 122°F)
Storage Temperature:-10° to 55°C (14° to 131°F)
Humidity: 10% to 90% non-condensing
Applications:
Shielded and unshielded twisted pair cable, 75 or
50 ohm coaxial cable, 10 or 10/100 BASE-T
Networks
